9-inch quad reversing camera kit system, MS-791RSCQ system 9-inch digital LCD quad view monitor with 4-way AV inputs, automatic switching with 3 triggersFeatures:
1. 9" quad rear view system with 4CHs AV in
2. Automatic switching with three triggers
3. Single, dual, triple, quad image available
4. Mirror function for each camera can be separately set up
Supply voltage: 10-32V DC and built-in speaker
5. Dust- and waterproof design, all connectors are waterproof
6. Meets the requirements for hot, cold weather also shock and vibration
7. 20G force for vibration and 100G for shock
With industrial applications
8. Normal/mirror mode built-in for each camera
9. Auto on when vehicle is placed in reverse
10. With USA imported IC and techwell industrial digital video processor
11. Short-circuit protection circuit design, avoid mistake connecting leading to the monitor's circuit damage
9'' quad LCD monitor MS-791Resolution: 800 x 3 (RGB) x 480p
Contrast: 300:1
Pixel pitch: (H) 0.0825 x (V) 0.2327s
Viewing angle:
U: 60°
D: 70°
L/R: 75°
Brightness: 350 nits
TV system: PAL and NTSC
Respond time: 30ms
Picture display format: 16:9
Eight languages OSD menu: Chinese, English, Russian, German, French, Italian, Portuguese and Spanish
Display with three video frequency input automatic/manual switcher
Includes flat surface/in-dash and adjustable Universal mounts
Front panel controls with on-screen menu
Operation temperature: -30 to +70°C
Optional CCD camera, MS-7501/3 CCD sharp sensor
Waterproof: IP68
Pixels:
NTSC: (H) 769 x (V) 494p
PAL: (H) 752 x (V) 582p
Resolution: 540 TV lines
Minimum light: 0 lux (LED on)
S/N ratio, more than 48dB
Video output: 1Vp-p 75
Voltage: 12V DC (+/-15%) 120 degrees
Optional CCD camera, MS-7701/3 CCD sharp sensor
Waterproof: IP68
Pixels:
NTSC: (H) 769 x (V) 494p
PAL: (H) 752 x (V) 582p
Resolution: 540 TV lines
Minimum light: 0 lux (LED on)
S/N ratio, more than 48dB
Video output: 1Vp-p 75
Voltage: 12V DC (+/-15%) 120 degrees
Optional CCD camera, MS-7801/3 CCD sharp sensor
Waterproof: IP68
Pixels:
NTSC: (H) 769 x (V) 494p
PAL: (H) 752 x (V) 582p
Resolution: 540 TV lines
Minimum light: 0 lux (LED on)
S/N ratio, more than 48dB
Video output: 1Vp-p 75
Voltage: 12V DC (+/-15%) 120 degrees
Mingshang International Group has its head office in the Shenzhen China and consists of Shenzhen mingshang industrial co, Ltd, Mingzong technology co, Ltd and Mingshang high technology(huizhou) co, Ltd
Found in 2003, Mingshang has produced excellence car visual safety solutions to the worldwide vehicles markets, is the one of China's leading suoopliers of backup camera system, Rear view camera system, mobile DVR and so on.
MINGSHANG is one of China's leading suppliers and manufacturers for Wired and Wireless Rear View Camera Systems, and Mobile DVR for
- Commercial and School Buse
- RV's and Motorhomes.
- Cargo and Delivery Vans.
- Trucks and Trailers.
Products:
1. Trailer camera system
2. Forklift camera system
3. HD heavy duty camera system in wired and digital wireless
4. Mobile DVR
5. Wireless hitch camera system---for trailer, horsebox, caravan, forklift, Boat
6. Recordering 4CH wireless camera system
MINGSHANG has over 14 years of experience in designing and developing visual safety systems for eliminating blind spots around vehicles to avoid the challenges that today's vehicles drivers face out on the open road.
MINGSHANG is proudly to server Ford, GMC, YUTONG BUS, KINGLONG, and Dometic (Waeco).
MINGSHANG certified with TS16949: 2009 & ISO9001: 2008 International Quality Management System since 2011, also compliant with RoHS requirements. The certificates include CE, FCC, and E-MARK...etc.
