Big Painting Booth/Large Spray Booth with Ce Standard
| Price: |
US $ 5999-999990/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal,Money Gram |
The large/industrial spray booth is customized size according to need. The following is just for example of our 9m spray booth.
Detailed Product Description9M Emergency Stop Energy Saving Insulation EPS Industrial Heat Spray And Baking Booth, Room| Booth Dimension |
| - Internal Size(L×B×H) | 9200x4500x3500mm |
| - External Size(L×B×H) | 9344x6396x4100mm |
| Foundation and Floor |
| - Grid | 2 rows air exhust plenum chamber |
| - Metal Basement | Need to build the base construction , 2 rows of pits in the ground for exhaust air, with galvanized grids made by twisted steel and flat bar above |
| Wall and Door |
| - Steel Wall | Double construction with insulations EPS , thickness 75mm, 0.5mm steel thickness ;
width:950mm, tongue and groove interlock structure,
with Polystyrene(EPS) insulation inside |
- 3-Folded Entrance Door
With Safety Glass Window | 1 Unit, 3500×3400 mm(WxH) , galvanized steel cover frame,
with polystyrene(EPS) insulation inside |
- Operator's Door With
Safety Glass Window | 1Unit, 650×2000 mm(W×H) |
| Lighting System |
| - Ceiling Lights | 12Units, each 4×36 W, with electronic ballasts. |
| - Side Lights | 12Units, each 2×30W, with electronic ballasts. |
| - Brightness | >1000LUX |
| Filter System |
| - Filter | 31M2 |
| Ventilation System |
- Intake air system
(Fresh Air) | 2x5.5KW double-intake centrifugal fans for intake air, model is YDW4.5M,
total air capacity is 30000m3/h |
- Exhaust
air system(Exhaust Air) | 1x7.5KW double-intake centrifugal fans for exhaust air, external motor, belt-drive, model TAE-710H, air capacity is 20000m3/h |
| - Damper actuates | Manual damper actuates from spraying to baking cycle, manual damper for exhaust air |
| Heating System |
| - Heating Exchange | Stainless Steel |
- Heating
Exchange Capacity | 260000Kcal/h |
- Max. Drying
Temperature | 80 °C |
| - Heating time | 10-15 min (from 20 to 60) by Drying Phase |
| - Heating Type (optional) | RIELLO RG5S (260000 kcal/h)Diesel )1set |
| Control Box |
| - Control system | Spraying, heat spraying, baking, time setting, lighting switch, failure indicator,
thermostat, power supply switch, emergency stop, ampere meter, voltmeter,
hour meter, temperature limit controller, pressure gauge, exhaust reduction
voltage motor start |
| - Total power | 22KW |
Basic Draw
Real Photo for our airplane booth
the same price higher quality, the same quality lower prices.
*2 years quality warranty!!!
*Fast and stable supply ability!!!
*Personalized design to meet customer various needs!!!
Over 14 years big spray booth factory;
Powder coating technology treatment;
Factory price and best quality;
OEM available.
| Prod Model: |
GW-I07 |
| Inside Size: |
9200X4500X3500mm |
| Outside Size: |
9344X6396X4100mm |
| Front Door(mm): |
3000X1600(Wxh) |
| Intake Fan: |
2X5.5kw Double-Intake Centrifugal Fans for Intake |
| Exhaust Fan: |
1X7.5kw Double-Intake Centrifugal Fans for Exhaust |
| Heating System: |
Riello Rg5s (260000 Kcal/H)Diesel )1set |
| Certification: |
CCC |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Brand: |
Captain |
