Automobile Turbocharger Test Bench for Trucks, Cars
| Price: |
US $ 14500/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
QZY-2C Model Automobile Turbocharger Test Bench
1.Function Introduction
Automobile turbocharger test bench is applicable for testing performance of turbocharger on various models vehicles and can carry out dynamic test of boost pressure, air flow and lubrication of turbocharger.
This test bench can carry out contrast test of inlet & outlet air pressure difference of various turbochargers and read the values
It adopts the advanced touch screen, control the test by touching the screen and read the test data immediately.
Soft keyboard inside, it can number, store and keep file for reference of the tested turbocharger, and print the test result and wave form curve with a printer. It achieves comprehensive dynamic test and data record of turbocharger.
2. Technical Parameter
Power: AC AC380V 50HZ (made to Measure)
Power of airflow generator: 5.5KW (made to order)
Frequency converter power: 7.5KW
RPM of airflow generator: 0--20000r/min
Maximum air pressure of airflow generator: 5KPa
Maximum flow rate of airflow generator: 1500m³/h
Power of oil pump motor: 750W
Rated pressure of oil pump: 0.3MPa
Maximum displacement of oil pump: 15L/min
MOQ: 1 set
Panel: English
Delivery time : 35-40days
Payment term:
T/T 50% in advance,50% before delivery
Packing :
Export Plywood case
1830*1050*1685mm=3.24CBM
930*750*1020mm=0.71CBM
Total: 3.95CBM
| Prod Model: |
QZY-2C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
380V 50Hz |
| Motor Power: |
7.5kw |
| Update Method: |
by Hard Disk |
| Certification: |
ISO |
Established in 1984, Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of automobile maintenance and test equipment. We obtained tens of national patent on some related products. Our main products are automobile test benches, such as electric universal test bench, alternator/generator test bench, starter test bench, engine test bench, turbocharger test bench, air compressor test bench, braking system test bench, steering gear and power pump test bench, AC compressor test bench, clutch test bench, automatic gearbox/transmission test bench, etc, brake shoe riveting and grinding machines, electric/ manual hydraulic presses, auto pit jack/lift, and so on. We can also design and make specially according to customers' request.
We are located in Qingdao city, Shandong province, with convenient transportation access. Our factory is thirty minutes' drive to Qingdao airport, and two hours' drive to the loading port.
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. We have passed the ISO9001-2008 international quality system authentication. We gained many honors in automobile maintenance and repair industry, we are a standing member of the China Automobile Maintenance and Repairing Equipment Trade Association, One of the ten most influential company in automobile maintenance and repair industry, we are also a designated factory by General Armament Department of CPLA.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Our sales network covers North America, South America, European, South Africa, Russia, Asia, Middle East, etc.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are also sincerely looking for steady and long-term cooperative local agents in different areas. We are looking forward to forming successful business relationships with new clients around the world in the near future.
