Prod Model: |
529891AB BA2B633313C 40BWD12 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Delivery: |
Stock |
Type: |
Wheel Hub Bearing |
Material: |
Chrome Steel |
Clearance: |
C3 |
Tolerance: |
P0 |
ABS: |
Without ABS |
Certification: |
ISO9001 |
Application: |
All Cars |
Brand: |
Ikc SKF NSK NTN Timken Hrb Zwz Lyc |
Product Description
Quick Details
Model: | 529891AB BA2B633313C 40BWD12 | Structure: | Whelel HUb Bearing | Type: | Whelel HUb Bearing |
Brand Name: | NSK SKF NTN | Material: | Gcr15 chrome steel | Seals Type: | open |
Packaging & Delivery
Delivery Detail:as cosumers' request
Specifications
Auto Wheel Hub Bearing Wheel Bearing NSK KOYO 529891AB BA2B633313C 40BWD12
Wheel hub bearings (hub bearing) is mainly used for the rotation of the wheel hub bearing and provide precise guidance, it is under axial load and bear radial load, is a very important parts. Traditional car wheel with bearing is by two sets of tapered roller bearing or ball bearing combination and become, bearing installation, oil, seal and clearance adjustment are in the car on the production line. This structure makes it in the car factory assembly difficulty, the high cost and poor reliability, and the car maintenance station maintenance, also need to bearing for cleaning, oil and adjustment. Wheel hub bearing unit is in the standard angular contact ball bearings and tapered roller bearing developed on the basis of, it will be two sets of bearing assembly as an organic whole, have good performance, can be omitted the clearance adjustment, light weight, compact structure, load capacity, for sealed bearing can advance in grease, ellipsis external hub seal and from maintenance etc, and has been widely used in cars, in truck also.
LGZC No. | Basic Dimensions (mm) | Type | Mass(kg) | Ref. No. | Applicable models |
d | D | B | C | Approx. | KOYO | FAG | SKF | SNR | NSK |
DAC255200206 | 25 | 52 | 20.6 | 20.6 | A | 0.19 | | | 617546A | | | Fiat ,Seat |
DAC25520037 | 52 | 37 | 37 | C | 0.33 | | 576467 | 445539AA | FC12025S01 | | Renault, Peugeot, Citroen |
DAC25520042 | 52 | 42 | 42 | C | 0.36 | | | | | 25BWD01 | |
|
DAC25560032 | 56 | 32 | 32 | D | 0.35 | | | BAH5000 | | | |
|
DAC27600050 | 27 | 60 | 50 | 50 | C | 0.42 | | | | | 27BWD01J | |
|
DAC28580042 | 28 | 58 | 42 | 42 | B | 0.41 | DAC28582RK | | | | 28BWD03A | |
|
DAC28610042 | 61 | 42 | 42 | - | 0.51 | DAC286142AW | | | | 28BWD01A | Toyota |
DAC30550026 | 30 | 55 | 26 | 26 | A | 0.32 | | | | | 30BWD08 | |
|
DAC30600037 | 60 | 37 | 37 | A | 0.46 | DAC3060372RS | | | | | Fiat, LadaLancia, Seat,Volvo |
DAC30600337 | 60.03 | 37 | 37 | A | 0.41 | DAC3060W | 529891AB | BA2B633313C | GB10790S05 | | Fiat, LadaLancia, Seat,Volvo |
DAC30600342 | 63.03 | 42 | 42 | - | 0.56 | DAC3063W-1 | | | | | |
|
DAC30630042 | 63 | 42 | 42 | A | 0.57 | | | | | 30BWD01A | |
|
DAC30640042 | 64 | 42 | 42 | B | 0.58 | DAC3064W2RKB | | | | | |
|
DAC30650021 | 65 | 21 | 21 | A | 0.27 | | 522372 | BB1B630374 | | | Fiat,Seat, Polski |
DAC30680045 | 68 | 45 | 45 | C | 0.72 | | | | | 30BWD04 | |
|
DAC32720045 | 32 | 72 | 45 | 45 | B | 0.81 | | | | | 32BWB05 | |
|
DAC32730054 | 73 | 54 | 54 | B | 0.98 | DAC3273W | | | | | |
|
DAC34620037 | 34 | 62 | 37 | 37 | C | 0.42 | DAC34620037 | 561447 | BAHB311316B | | | Audi, Volkswagen, Chrysrle |
DAC34640034 | 64 | 34 | 34 | D | 0.43 | DAC3464D | | | | | |
|
DAC34640037 | 64 | 37 | 37 | C | 0.5 | DAC3464G12RS | 532066DE | 309726DA | GB10884 | 34BWD11 | Lada,Ople, Vlkswagen, Bedford |
DAC34640037A | 64 | 37 | 37 | C | 0.5 | DAC3464W-22RS | | | | | |
|
DAC34660037 | 66 | 37 | 37 | C | 0.52 | | 580400CA | 636114A | | 34BWD10B | Ople, Vauxhall, Accord |
DAC34680037 | 68 | 37 | 37 | B | 0.55 | DAC3468DW | | | | 34BWD08A | |
|
DAC34680037A | 68 | 37 | 37 | A | 0.55 | DAC34682RS | | | | | |
|
DAC34680042 | 68 | 42 | 42 | C | 0.64 | DAC34682RS | | | | 34BWD09A | |
|
DAC35640037 | 35 | 64 | 37 | 37 | D | 0.41 | DAC3564A-1 | | BAH0042 | | | Daihastu |
DAC35640037A | 64 | 37 | 37 | D | 0.46 | DAC3564A | | | | | |
|
DAC35650035 | 65 | 35 | 35 | C | 0.43 | DAC3565WCS30 | 546238A | BT2B445620B | GB12004 | | Renault |
DAC35650037 | 65 | 37 | 37 | B | 0.48 | | | | | 35BWD19E | |
|
DAC35660032 | 66 | 32 | 32 | C | 0.4 | DAC3566 | | 445980A | | | Citroen |
DAC35660033 | 66 | 33 | 33 | C | 0.42 | | | BAHB633676 | GB12306S01 | | Fiat |
DAC35660037 | 66 | 37 | 37 | C | 0.49 | DAC35660037 | 544307D | BAHB311309 | GB12136 | | Volkswagen |
DAC35680037 | 68 | 37 | 37 | A | 0.53 | DAC3568A2RS | 541153A | BAHB633295B | GB10840S02 | | Fiat, LanciaSeat, Volvo, Zastava |
DAC35680033/30 | 68 | 33 | 30 | C | 0.48 | | | | | 35BWD07A | |
|
DAC35680233/30 | 34.99 | 68.02 | 33 | 30 | - | 0.49 | DAC3568W-6 | | | | | Nissan |
DAC35680038/36 | 35 | 68 | 38 | 36 | - | 0.5 | | | | | 35BWD16 | |
|
DAC35720028 | 72 | 28 | 28 | - | 0.46 | | | | | | Citroen, Peugeot, Renault, Simca, Talbot |
DAC35720228 | 72.02 | 28 | 28 | - | 0.48 | | 544033 | BA2B441832AB | GB10679 | | Citroen, Peugeot, Renault, Simca, Talbot |
DAC35720033 | 72 | 33 | 33 | C | 0.58 | DAC357233B-1W | 548083 | BA2B445535AE | GB12094S04 | | Citroen, Peugeot |
DAC35720033/31 | 72 | 33 | 31 | B | 0.55 | | | | | 35BWD06A | |
|
DAC35720233/31 | 72.02 | 33 | 31 | - | 0.54 | DAC357233B1 | 562686 | FWB14 | | | |
|
DAC35720034 | 72 | 34 | 34 | - | 0.58 | DAC357234A | 540763 | | DE0763CS46PX1 | | Lzw7100, Honda |
DAC35720433 | 72.04 | 33 | 33 | C | 0.57 | | | BAHB633669 | GB12862 | | Fiat, Lancia |
DAC35720045 | 72 | 45 | 45 | A | 0.63 | DAC357245CW2RS | | | | | |
|
DAC35770442 | 34.99 | 77.04 | 42 | 42 | - | 0.86 | DAC3577W-3 | | | | | |
|
DAC35800045 | 35 | 80 | 45 | 45 | B | 1.1 | DAC3580W-3HR4 | | | | | |
|
DAC35800047 | 80 | 47 | 47 | A | 0.96 | DAC358047BW2RS | | | | | |
|
DAC35800047A | 80 | 47 | 47 | A | 1.03 | DAC3580WHR4 | | | | | |
|
DAC36650037 | 36 | 65 | 37 | 37 | - | 0.45 | DAC3665W | | | | | |
|
DAC36680033 | 68 | 33 | 33 | - | 0.48 | DAC3668AW | | | | 36BWD04 | Suzuki |
DAC36680033A | 68 | 33 | 33 | - | 0.47 | DAC3668W | | | | | |
|
DAC36720042 | 72 | 42 | 42 | A | 0.68 | | | | | 36BWD03 | |
|
DAC36720534 | 72.04 | 34 | 34 | - | 0.57 | DAC367234A | | | | 36BWD01B | Chrysrle, Honda |
DAC367600292/27 | 76 | 29.2 | 27 | D | - | | | 440 190 | | | |
|
DAC37720233 | 37 | 72 | 33 | 33 | - | - | | | | GB40547 | | |
|
DAC37720037 | 72 | 37 | 37 | C | 0.6 | | | | GB12807S03 | | Fiat, Ford, Lancia, Renault, Chrysrle |
DAC37720237 | 72.02 | 37 | 37 | C | 0.6 | | 527 631 | BA2B633028CB | GB12258 | | |
|
DAC37720437 | 72.04 | 37 | 37 | C | 0.6 | | 5623 98A | 633531B | GB12131S03 | | Alfa Romeo, Fiat, Lancia Chrysrle, Renault |
DAC37740045 | 74 | 45 | 45 | C | 0.81 | | 541521C | 309946AC | | 37BWD01 | |
|
DAC38700037 | 38 | 70 | 37 | 37 | A | 0.48 | | | | | 38BWD19 | |
|
DAC38700038 | 70 | 38 | 38 | B | 0.55 | DAC3870DW | | 686908A | | | 7100Charde |
DAC38700038B | 70 | 38 | 38 | D | 0.57 | | | | | 38BWD21 | |
|
DAC38710233/30 | 37.99 | 71.02 | 33 | 30 | - | 0.5 | DAC3871W-2 | | FW135 | | 38BWD09A | |
|
DAC38710039 | 38 | 71 | 39 | 39 | B | 0.62 | | | | | 38BWD22 | |
|
DAC38720034 | 72 | 34 | 34 | - | 0.59 | DAC3872A | | | | 38BWD04 | |
|
DAC38720040 | 72 | 40 | 40 | D | 0.63 | DAC3872W-10 | 575069B | FW102 | | | |
|
DAC38720236/33 | 37.99 | 72.02 | 36 | 33 | - | 0.56 | DAC3872W-8 | | VKBA 1191 | | 38BWD12 | Honda,Rover |
DAC38730040 | 38 | 73 | 40 | 40 | D | 0.67 | DAC3873-1 | | | | | |
|
DAC38740236/33 | 37.988 | 74.02 | 36 | 33 | - | 0.62 | DAC3874W-6 | | | | 38BWD24 | Toyota |
DAC38740236/33B | 37.99 | 74.02 | 36 | 33 | - | 0.61 | | | | | 38BWD15 | |
|
DAC38740040 | 38 | 74 | 40 | 40 | A | 0.69 | | | | | 38BWD10B | |
|
DAC38740050 | 74 | 50 | 50 | D | 0.78 | | 559 192 | FWB 116 | | 38BWD06D | |
|
DAC38740450 | 74.04 | 50 | 50 | D | 0.79 | | | | | | Nissan |
DAC38760043 | 76 | 43 | 43 | B | 0.82 | | | | | 38BWD23A | |
|
DAC38800036/33 | 80 | 36 | 33 | - | 0.79 | | | | | 38BWD18 | |
|
DAC38800236/33 | 37.967 | 80.02 | 36 | 33 | - | 0.79 | DAC3880W-1 | | | | | |
|
DAC39680037 | 39 | 68 | 37 | 37 | B | 0.49 | DAC39680037 | 540733BA | BAHB311315 BD | | 39BWD03 | Volkswagen, Ford,Audi, Santana |
DAC39720037 | 72 | 37 | 37 | C | 0.58 | DAC3972D2RSF | 542186A | BAHB311396B | GB12776 | 39BWD01L | BMW,Opel, Ford, Bedford, Vauxhall |
DAC39720037A | 72 | 37 | 37 | C | 0.5 | DAC3972AW4 | | | | | |
|
DAC39720637 | 72.06 | 37 | 37 | B | 0.57 | | 542186CA | | | | |
|
DAC39740039 | 74 | 39 | 39 | C | 0.68 | | | | | 39BWD05 | |
|
DAC39/41750037 | 39/41 | 75 | 37 | 37 | C | 0.64 | DAC39/41750037 | 567447B | BAHB633815A | GB12399S01 | | Audi |
DAC40700043 | 40 | 70 | 43 | 43 | D | 0.63 | DAC407043W | | | | | |
|
DAC40720037 | 72 | 36 | 33 | - | 0.53 | DAC4072 | | | | | |
|
DAC40720037 | 72 | 37 | 37 | C | 0.56 | | 566 719 | BAHB 311 443B | GB12 320S 02 | | Volkswagen Seat |
DAC40740036/34 | 74 | 36 | 34 | - | 0.62 | DAC4074CW | | | | 40BWD16 | Proton |
DAC40740036 | 74 | 36 | 36 | D | 0.64 | | | | | 40BWD15A | |
|
DAC40740040 | 74 | 40 | 40 | C | 0.66 | DAC407440 | | | | 40BWD06D | |
|
DAC40740042 | 74 | 42 | 42 | B | 0.71 | | | | | 40BWD12 | |
|
DAC40750037 | 75 | 37 | 37 | C | 0.63 | | 559 494 | BAHB633966E | | | Ford |
DAC40760033 | 40 | 76 | 33 | 33 | D | 0.61 | | | 474743B | 555 800 | 40BWD08A | |
|
DAC40760033/28 | 76 | 33 | 28 | A | 0.55 | | 539166AB | 474 743 | | | Chrysrle, Volkswagen, Rover |
DAC40760041/38 | 76 | 41 | 38 | C | 0.7 | DAC407612RS | 559226 | FW124 | | 40BWD05 | |
|
DAC408000302 | 80 | 30.2 | 30.2 | - | 0.68 | | 523854 | 440320H | Y44F B10394S01 | | |
|
DAC40800031 | 80 | 31 | 31 | D | 0.66 | | | BA2B445469BA | | | |
|
DAC40800036/34 | 80 | 36 | 34 | - | 0.74 | DAC4080M1 | | FWB101 | | 40BWD14 | GM, Mitsubishi |
DAC40820040 | 82 | 40 | 40 | A | 0.88 | | | | | | |
|
DAC40840338 | 84.03 | 38 | 38 | C | 0.98 | | | | | | |
|
DAC401080032/17 | 108 | 32 | 17 | - | - | | | BA2B 445 533 | TGB1 0872 S02 | | |
|
DAC42750037 | 42 | 75 | 37 | 37 | A | 0.6 | DAC427 5BW2RS | 5454 95D | BA2B 633 457 | GB12 010 | | Alfa Romeo, Audi, Porsche, Saab |
DAC42760033 | 76 | 33 | 33 | C | 0.65 | | | | 555 801 | 42B WD12 | |
|
DAC42760038/35 | 76 | 38 | 35 | A | 0.56 | | | | | 42BWD06 | Nissan |
DAC42760040/37 | 76 | 40 | 37 | A | 0.66 | DAC427602RSF | 547059A | 909 042 | | | |
|
DAC42780038 | 78 | 38 | 38 | C | 0.7 | DAC4278A2RS | | | | 42BWD09 | |
|
DAC42780041/38 | 78 | 41 | 38 | C | 0.75 | DAC4278C2RS | | | | | |
|
DAC42800036/34 | 80 | 36 | 34 | - | 0.76 | | | | | 42BWD13 | |
|
DAC42800037 | 80 | 37 | 37 | D | 0.7 | | | BAHB 633 770 | | | |
|
DAC42800045 | 80 | 45 | 45 | B | 0.86 | DAC4280W-2 | | | | 42BWD11 | |
|
DAC42800045A | 80 | 45 | 45 | - | 0.85 | DAC4280WHR4 | | | | | |
|
DAC42800342 | 80.03 | 42 | 42 | A | 0.82 | DAC4280B2RS | 527243C | BA2B309609AD | | | |
|
DAC42820036 | 82 | 36 | 36 | C | 0.76 | DAC4282 | 561481 | BA2B446047 | GB12163S04 | | Citroen, Peugeot, GM |
DAC42820037 | 82 | 37 | 37 | C | 0.8 | | 565636 | BAHB311413A | GB12269 | | Audi |
DAC42840036 | 84 | 36 | 36 | A | 0.84 | | 564727 | BA2B444090AB | GB10857S02 | | Peugeot, Simca, Talbot |
DAC42840039 | 84 | 39 | 39 | A | 0.95 | | 543359B | 440090 | GB10702S02 | |
Part No. | | d | D | T | B | C | | | | | | |
JRM2525/2552XD | 25 | 52 | 37 | 18.5 | 37 | | | | | | |
JRM255243 | | 25 | 52 | | 21.5 | 43 | | | | | | |
27KWD02G3CA102 | 27 | 52 | | 22.5 | 43 | | | | | | |
E-21003203 | | 30 | 60.3 | | 18.5 | 37 | | | | | | |
E-21003212 | | 35 | 65 | | 17.5 | 35 | | | | | | |
JRM377237 | | 37 | 72 | | 18.5 | 37 | | | | | | |
UCF346437 | | 34 | 64 | 37 | 18.5 | 37 | | | | | | |
JRM3535/65XD | | 35 | 65 | 35 | 17.5 | 35 | | | | | | |
JRM3939/JRM3968XD | 39 | 68 | 37 | 18.5 | 37 | | | | | | |
JRM3939/JRM3972XD | 39 | 72 | 37 | 18.5 | 37 | | | | | | |
JRM3940/JRM4072XD | 40 | 72 | 37 | 18.5 | 37 | | | | | | |
JRM4040/4072XD | 40 | 72 | | 18.5 | 37 | | | | | | |
JRM4242/4282XD | 42 | 82 | | 18 | 36 | | | | | | |
| | 49 | 84 | 43 | 21.5 | 43 | | | | | | |
JXC25469C |
JXC25469CA | | 49 | 84 | 48 | 24 | 48 | | | | | | |
FC40096 | | 45.3 | 80 | | 24 | 48 | | | | | | |
BTH1011AB | | 55 | 90 | | 30 | 60 | | | | | | |
BTH1024 | | 40 | 73 | | 27.5 | 55 | | | | | | |
