7 Inch Waterproof Rear View System with IP69k Reaview Camera for Truck

Name: 7 Inch Waterproof Rear View System with IP69k Reaview Camera for Truck
Brand: ibuyautoparts.com
SKU: 795014495
Availability: InStock
Rating: 4.8 (75 reviews)

Price:	US $ 85-120/Set
Min Order:	1/Set
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Rear View System/ 7inch Monitor and Dome Camera for Bus Surveillance

Monitor Specification:
. Screen size: 7 inch new TFT panel
. Aspect Ratio: 16:9 image
. Input: 4-way video input with 4 reversing cable
. System: PAL and NTSC auto switching
. Resolution: 800 x R.G.B x480
. Brightness: 450cd/m2
. Power supply: 9-36V DC
. Built-in speaker
. Operation Temperature: -20ºC~+70ºC.RH95% Max
. Storage Temperature: -30ºC~+80ºC.RH95% Max

BR-DV002
Camera Specification:
- Image Sensor : 1/3" Color CCD
- Resolution:420TVL
- Electronics Shutter:1/60-1/5000(S)
- Lens:2.8mm/2.1mm
- Wide angle: 120°
- Power:12V DC(+/-10%)
- Night vision
- Easy for installation

Monitor Specifications:
- Screen size: 7-inch panel (diagonal length)
- Input: 2-way video input
- System: PAL and NTSC auto switching
- Resolution: 480 x R-G-B x 234
- Power supply: 12-24V DC
- Built-in speaker (optional)
- Heavy duty  reversing
- OSD menu
- contrast, color, brightness adjustable
- View angle range: (left/right) 65 degrees (top) 40 degrees
  (down) 15 degrees

Screen size	7 inch
Resolution	800480RGB
System	PAL/NTSC automatically
Audio and video	4 video/1audio input Quad images,2/3/4 image optional
OSD menu	Language,brightness, contrast, trigger priority delay display setting
Luminance	250cd/SM
Working temperature	-20°C-+70°C
Storage temperature	-30°C-+80°C
Voltage	12V-24V DC
Connector	4 pin or RCA
Accessories	user manual/remote controller/powr calbe/sunshade/scre

Collocation:

Aluminum Shell Backup Waterproof Camera

Image Type: 1/3 Inch Color CCD

Horizontal Resolution:720TV Lines

NTSC:976(H)×494(V) PAL:976(H)x582(V)

Usable Illumination : 0Lux ( Built in 10 IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: 100% Waterproof IP69K Rating

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Operating temperature: -40ºC to +70ºC (Automatic heating when the camera's running temperature is below 10ºC optional)

Power supply:DC12V (from Reversing Monitor)

Dimensions: 75(W) x 43(H) x 38(D) mm (without mounting)

Weight Approx: 179g

Prod Model:	BR-704WP&RVC06
Size:	7 Inches
Brand:	Brvision
Definition:	420TVL
Chip:	CCD
Waterproof Grade:	IP68
Interface:	4 Pin Connector

BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products

Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.

Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.

It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.

BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.

We specialize in:

. Vehicle Rearview Camera(CCD or CMOS)

. Vehicle TFT LCD Monitor

. Wireless Transmitter and Receiver

. Surveillance Camera

. OEM and ODM Project

BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
