5.6 Inch TFT LCD Monitor System

Name: 5.6 Inch TFT LCD Monitor System
Brand: ibuyautoparts.com
SKU: 754016995
Availability: InStock
Rating: 5 (104 reviews)

Price:	US $ 120/Set
Trade Terms:	FOB,EXW
Min Order:	1/Set
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Key features:

- 5.6" TFT LCD monitor
- Rearview camera with night vision
- This system for front view monitor
- The rearview camera is for option

Monitor specifications:

- Screen size: 5.6-inch digital panel (4:3)
- Input: 2-way video input
- System: PAL and NTSC switching
- Resolution: 320 x R-G-B x 240
- Power supply: 12-24V DC
- Built-in speaker
- Heavy-duty reversing
- Remote control, OSD menu
- Contrast, color, brightness adjustable
- Three video input with 2 trigger cables
- Operating temperature: -20 to +70°C
- Storage temperature: -30 to +80°C

BR-RVC05
Camera specifications:
- Image sensor : 1/4" Sharp/Sony color CCD
- TV system: NTSC/PAL
- IP rating: IP65
- Vibration rate: 10G
- Effective pixels N: 510×492 pixels, P: 500×582 pixels
- Horizontal resolution: 420TVL
- Video output: 1.0vp-p, 75Ω
- Built-in lens: 2.8mm
- Wide angle: 120°
- Power supply: 12V DC (±10%)
- Power consumption: <3W
- Silver aluminum housing
- Operating temp: - 20 to +70°C
- Storage temp: - 30 to +80°C

Aluminum Shell Backup Waterproof Camera

Image Type: 1/3 Inch Color CCD

Horizontal Resolution:720TV Lines

NTSC:976(H)×494(V) PAL:976(H)x582(V)

Usable Illumination : 0Lux ( Built in 10 IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: 100% Waterproof IP69K Rating

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Operating temperature: -40ºC to +70ºC (Automatic heating when the camera's running temperature is below 10ºC optional)

Power supply:DC12V (from Reversing Monitor)

Dimensions: 75(W) x 43(H) x 38(D) mm (without mounting)

Weight Approx: 179g

Prod Model:	TM5601&RVC05
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Screen Size:	5.6 Inch Digital Panel
System:	PAL and NTSC Switching
Resolution:	320 X R-G-B X 240
Image Senso:	1/4" Sharp/Sony Color CCD
Waterproof:	IP65
Definition:	420TVL
Chip:	CCD
Waterproof Grade:	IP68
Interface:	4 Pin Connector

BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products

Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.

Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.

It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.

BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.

We specialize in:

. Vehicle Rearview Camera(CCD or CMOS)

. Vehicle TFT LCD Monitor

. Wireless Transmitter and Receiver

. Surveillance Camera

. OEM and ODM Project

BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
