5.6 Inch Bus Monitor System

Name: 5.6 Inch Bus Monitor System
Brand: ibuyautoparts.com
SKU: 754590115
Availability: InStock
Rating: 4.4 (44 reviews)

Price:	US $ 120/Set
Trade Terms:	FOB,EXW
Min Order:	1/Set
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

5.6 Inch Bus Monitor / 2 Way Video Inputs /Ceiling Camera
Monitor Specifications:
. Screen size: 5.6 inch Digital panel (16:9)
. Input: 2-way video input
. System: PAL and NTSC switching
. Resolution: 320 x R.G.B x 234
. Power supply: 12-24V DC
. Bui lt-in speaker
. Heavy duty reversing
. Remote control, OSD menu
. contrast, color, brightness adjustable
. Three video input with 2 trigger cable.
. Operating temperature: -20ºCto +70ºC
. Storage temperature: -30ºC to +80ºC

BR-RVC05
Camera Specification:
- Image Sensor : 1/4" Sharp/Sony Color CCD
- TV System: N TSC/ PAL
- IP Rating: IP65
- Vibration Rate: 10G
- Ef fective Pixels N: 510×492 pixels P: 500×582 pixels
- Horizontal Resolution: 420TVL
- Video Output : 1.0vp- p,75Ohm,
- Built-in Lens:2.8mm
- Wide angle: 120°
- Power Supply: 12V DC(+/-10%)
- Power consumption: <3W
- Silver Alluminium housing.
- Oper at i ng Temp: - 20C° t o +70C°
- Storage Temp: - 30C° t o +80C°

Aluminum Shell Backup Waterproof Camera

Image Type: 1/3 Inch Color CCD

Horizontal Resolution:720TV Lines

NTSC:976(H)×494(V) PAL:976(H)x582(V)

Usable Illumination : 0Lux ( Built in 10 IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: 100% Waterproof IP69K Rating

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Operating temperature: -40ºC to +70ºC (Automatic heating when the camera's running temperature is below 10ºC optional)

Power supply:DC12V (from Reversing Monitor)

Dimensions: 75(W) x 43(H) x 38(D) mm (without mounting)

Weight Approx: 179g

Prod Model:	RVC05&TM5601
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Screen Size:	5.6 Inch Digital Panel (16:9)
Input:	2-Way Video Input
System:	PAL and NTSC Switching
Resolution:	320 X R.G.B X 234
Power Supply:	12-24V DC
Bui Lt-in Speaker:	Yes
Image Sensor:	1/4" Sharp/Sony Color CCD
IP Rating:	IP65
Horizontal Resolution:	420tvl
Wide Angle:	120°
Definition:	420TVL
Chip:	CCD
Interface:	4 Pin Connector
Waterproof Grade:	IP65

BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products

Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.

Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.

It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.

BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.

We specialize in:

. Vehicle Rearview Camera(CCD or CMOS)

. Vehicle TFT LCD Monitor

. Wireless Transmitter and Receiver

. Surveillance Camera

. OEM and ODM Project

BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
