360-Degree Panoramic View Night Vision Car Camera/Bus Side View Camera
| Price: |
US $ 22-40/Piece |
| Trade Terms: |
FOB,FCA,EXW |
| Min Order: |
2/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
VC-V6002 Car camera |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sensor: |
1/3 Sony CCD |
| Car Make: |
Car, Bus, Truck and So on |
| Image Type: |
CCD (for Option) |
| Resolution(Pixels): |
PAL: 500(H)*582(V), NTSC: 510(H)*492(V) |
| Horizontal Resolution: |
420TV Lines(480/540lines for Optional) |
| Power Supply: |
DC12V |
| Interface: |
Air Plug |
| Chip: |
CCD |
| Definition: |
420TVL |
| Waterproof Grade: |
IP55 |
Product Description
It is small camera which is for DVR
This camera together with suitable for monitoring children, old people and vehicle, houses, companies, shops and factories etc
The automatic day/night sensor and infrared LEDs to provide clear image in dull condition
Image Type CCD (Sony1/3, Sony1/4, SHARP1/4, for option)
Resolution(pixels): PAL: 500(H)*582(V), NTSC: 510(H)*492(V)
Lens: 2.8mm
Lens angle: 120°
Signal to noise ratio: >48dB
Horizontal Resolution: 420TV Lines, 480TVLines, 650TVLines for optional
PAL/NTSC Normal/Mirror image for optional
18 PCS LEDs for night vision
Power Supply: DC12V± 10%
Power Consumption: <2W
Operating Temperature Range: -20° C to +70° C
Dimension: 82(L)*73(W)*58(H)mm
Weight: 380g
Waterproof Rate: IP55
| Item | Specification |
| Image Type CCD | SONY1/3,SONY1/4, for optional |
| Type | PAL/NTSC |
| Horizontal Resolution | 420TV Lines , 480TVLines, 650TVLines, 700TVLines for optional |
| Resolution(pixels) | PAL:500(H)*582(V),NTSC:510(H)*492(V) ,For 420TVL |
| Lens | f = 2.4 to 3.6mm, F = 2.0mm |
| Lens angle | 90 to 120° |
| IR | IR night vision for optional |
| Infrared LED light | 12pcs |
| IR distance | 10m |
| Signal to noise ratio | >48dB |
| Minimum illumination | 0.05 lux/F 1.2 (0 lux/F1.2 with IR) |
| Horizontal synchronizing resolution | 15,625 to 15,734kHz |
| Vertical synchronizing resolution | 50 to 60Hz |
| Video output | 1.0vp-p, 75Ω |
| Audio | Built in microphone for optional |
| Mirror | Mirror image for optional |
| AGC & BLC | auto |
| Power Supply | DC8-28V±10% |
| Gamma consumption | 0.45 |
| Operating Temperature Range | -20 to 75, 95% RH maximum |
| Storage temperatures | -40 to 85, 95% RH maximum |
Company Overview
Shenzhen Vcomsky Technology Co., Ltd., simple named Vcomsky, is a high-tech enterprise engaged in researching, developing, manufacturing and marketing mobile security products and IP camera products. Founded in 1998, the company is now located in Nanshan district, the economic center of Shenzhen, and run by a strong team of R&D, sales and administration, it's manufacturer located in Longgan district. Ever since it's foundation, Vcomsky has achieved great success in developing high anti-vibration mobile dvrs, high-pixel cameras, and a series of HD IP cameras. with cutting-edge technology and advanced manufacturing facilities, we have become one of the largest suppliers of car security products in China!
The pursuit of quality
Vcomsky emphasizes the advanced enterprise management and regards quality as our lifeline. with thorough quality management system and advanced quality testing equipments, we can conduct various comprehensive performance testing to our products, such as "Low and High Temperature Test" "Vibration Test" "Salt Spray Test" "Swing Test" "Waterproof Test" and "Aging Test" etc^ And also we strictly follow the quality control process to grantee the products' stability.
Vcomsky has been certificated with the highest international level of quality management system in auto industry_ISO/TS16949: 2009, and also we are in strict accordance with the EU RoHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, EMARK etc.
Premium service
Premium service is the foundation to win trust from customers, so Vcomsky provides professional OEM and ODM services to meet various needs of customers. And also, with the belief of "Growing with customers" and "Customer oriented", we dedicate to manufacturing the best products and offering the most satisfying service, even exceeding the expectation of customers to realize mutual benefits.
Excellence and leading
Vcomsky had formed a professional R&D team since its inception. All the way, we have persistently invested new technologies, developed new products, and launched a series of powerful and innovative products to meet the market's demand.
In terms of mobile security products, mobile dvrs with multi-language operation, multi-channel video input, multi-style, multi-function selection, wide voltage input, and supply power to the cameras. The universal shock for mobile hard disk dvrs is very useful. Mobile cameras with wide viewing angle, night vision capabilities, attractive appearance, mini size etc. Our mobile security products apply to various kinds of vehicle, such as trucks, buses, ambulances, garbage trucks, fire engines, agricultural vehicles, concrete mixer lorries, excavators, forklifts, road sweepers, cranes and etc. Relying on quality and outstanding styles, Vcomsky products are exported to many developed countries, such as United States, Britain, Germany, Japan and France. We have established long-term mutually beneficial partnership with many world famous enterprises.
In terms of HD IP cameras products, We have developed full series of IP cameras products, include; HD IPCAM, 3G IPCAM, SD IPCAM, and video management software. We own all source code of our products and can provide professional OEM and ODM customize service for global customer. We can print your logo or brandname on our products, even design the housing and package of products for you!
Humanity Harmony
Vcomsky adheres to the belief of People-oriented, so we provide competitive salary and welfare, equal opportunities of development, harmonious and comfortable working environment. These give employees a sense of stability, satisfaction, achievement and belonging, which in turn lays a solid foundation for our long-run development.
Vcomsky will always stand ready to cooperate with you. Let's grow together!
