26", 56" Truck (Bus) Tire Changer

56 inch TIRE CHANGER

Tire Changer for Trucks and tractors and earth moving machinery 56"
Very practical bead breaking device hand-operated by knob
Tire lifting lever
Pliers clamp

Optional:

Roller device for tubeless
Pair of bead clamps
Pliers for alloy rims
Set of 4 extensions 56"
Bead guide lever
Set of 4 jaws for alloy rims

TECHNICAL FEATURES

Wheels 14 to 56 inch
Max wheel diameter 90 1/2 inch
Max wheel width 42 inch
Electrical voltage 220V 3-phase 60Hz
Weight 1, 694lb


TRUCK TIRE CHANGER (10"~26")

All movement of the working parts are guided by the movable control platform,
Particularly suitable for handling truck wheel, farm wheels, passenger car
Wheels and industrial vehicle wheels between 14" and 26" with deep grooved rims, with ring. It is ideal mechanized equipment for maintenance wheel, for it saves time and labor with high efficiency, which does not damage to the in side of the rubber wheel and rim.
- Full automatic control working arm lift
- Movable control platform
- Working arm with quick rotation system
- Four oil cylinder

Max. Wheel diameter: 63"(1600mm)
Handles wheels from: 14" to 26"
Max. Wheel width: 31"(800mm)
Max. Wheel weight: 1270Kg
Hydraulic pump motor: 1.1Kw 1.5Kw 2.2Kw
Operating pressure: 0-130bar
Power supply: 380V3pH 220V3pH 220V1pH
Motor power: 1.5Kw 1.5Kw 2.2Kw
Net weight: 720Kg
Noise: <70dB
Packing outside dimension: 2245x1775x960mm
