| Unit Type | Starter |
| Part Type | UNIT |
| Voltage | 12 |
| Rotation | CCW |
| Teeth | 13 |
| KW | 1.4 |
| Manufacturer | DENSO |
| Starter Type | OSGR |
| Brief | LEXUS TOYOTA 1998-ON
ADDL INFO: BATTERY TERMINAL OPPOSITE
SEARCH: 484921
484922
484923 484924 (EARLIER STYLES) |
| Detailed | This is a Denso Starter for the 1998-On Lexus and Toyota Models. This Unit Looks Similar to the 17715 Used on the Same Models in Earlier Years EXCEPT the Battery Terminal on the Opposite Side of the Solenoid Case and the Ignition Terminal is on the Bottom of the Solenoid Case Pointing to the Rear. |
| SND0253 | ARROWHEAD |
| BSR3274X | ARROWHEAD (OEM) |
| 17774 | LESTER |
| 190-393D | PIC |
| 016172 | ANDRE NIERMANN |
| 610-17774 | BARSANCO |
| 17774 | BBB |
| 19617 | BBB (OLD) |
| 17774 | BBB NEW |
| N17774 | BBB NEW |
| B17774 | BBB PACE |
| 187-0676 | BECK ARNLEY |
| 112367 | CARGO |
| 228000-6170 | DENSO |
| 228000-6171 | DENSO |
| 228000-6172 | DENSO |
| 228000-6173 | DENSO |
| 228000-6280 | DENSO |
| 228000-6281 | DENSO |
| 228000-6282 | DENSO |
| 228000-6283 | DENSO |
| 280-0174 | DENSO FIRST TIME FIT |
| 9622809-628 | DENSO REMAN |
| S-8772 | DIXIE |
| 917774 | DUBOIS |
| 21270 | EXCEL |
| 410-52097 | J & N |
| LRS01659 | LUCAS ELECTRICAL EUROPE |
| 57-2837 | MINNPAR |
| 17774 | MPA |
| 44-6732 | NAPA |
| 4N-6732 | NAPA POWER NEW |
| 244-6732 | NAPA POWER PREMIUM PLUS |
| 44-6732 | NAPA POWER SUPREME |
| STR-8085 | NSA |
| ST-17774 | RCP |
| 28100-03100 | TOYOTA |
| 28100-74260 | TOYOTA |
| STR-8085 | UNIPOINT |
| S1546 | USA INDUSTRIES |
| 2-1984-ND | WAI |
| 91-29-5462 | WILSON |
| 91-29-5462 | WILSON NEW |
| 91-29-5462N | WILSON NEW |
| STR8085 | WOOD AUTO |
| 17610 | WORLDWIDE |
| LEXUS | Auto and Light Truck | ES300 | 1998 | 3.0L |
| LEXUS | Auto and Light Truck | ES300 | 1999 | 3.0L |
| LEXUS | Auto and Light Truck | ES300 | 2000 | 3.0L |
| LEXUS | Auto and Light Truck | ES300 | 2001 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 1999 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2000 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2001 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2002 | 3.0L |
| LEXUS | Auto and Light Truck | RX300 | 2003 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 1998 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 1999 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 2000 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 2001 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 2002 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 2003 | 3.0L |
| TOYOTA | Auto and Light Truck | AVALON | 2004 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 1998 | 2.2L |
| TOYOTA | Auto and Light Truck | CAMRY | 1998 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 1999 | 2.2L |
| TOYOTA | Auto and Light Truck | CAMRY | 1999 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2000 | 2.2L |
| TOYOTA | Auto and Light Truck | CAMRY | 2000 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2001 | 2.2L |
| TOYOTA | Auto and Light Truck | CAMRY | 2001 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2002 | 2.4L |
| TOYOTA | Auto and Light Truck | CAMRY | 2002 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2003 | 2.4L |
| TOYOTA | Auto and Light Truck | CAMRY | 2003 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2004 | 3.0L |
| TOYOTA | Auto and Light Truck | CAMRY | 2005 | 3.0L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2001 | 2.4L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2001 | 3.0L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2002 | 2.4L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2002 | 3.0L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2003 | 2.4L |
| TOYOTA | Auto and Light Truck | HIGHLANDER | 2003 | 3.0L |
| TOYOTA | Auto and Light Truck | RAV4 | 2001 | 2.0L |
| TOYOTA | Auto and Light Truck | RAV4 | 2002 | 2.0L |
| TOYOTA | Auto and Light Truck | RAV4 | 2003 | 2.0L |
| TOYOTA | Auto and Light Truck | RAV4 | 2004 | 2.4L |
| TOYOTA | Auto and Light Truck | RAV4 | 2005 | 2.4L |
| TOYOTA | Auto and Light Truck | SIENNA | 1998 | 3.0L |
| TOYOTA | Auto and Light Truck | SIENNA | 1999 | 3.0L |
| TOYOTA | Auto and Light Truck | SIENNA | 2000 | 3.0L |
| TOYOTA | Auto and Light Truck | SIENNA | 2001 | 3.0L |
| TOYOTA | Auto and Light Truck | SIENNA | 2002 | 3.0L |
| TOYOTA | Auto and Light Truck | SOLARA | 1999 | 2.2L |
| TOYOTA | Auto and Light Truck | SOLARA | 1999 | 3.0L |
| TOYOTA | Auto and Light Truck | SOLARA | 2000 | 2.2L |
| TOYOTA | Auto and Light Truck | SOLARA | 2000 | 3.0L |
| TOYOTA | Auto and Light Truck | SOLARA | 2001 | 2.2L |
| TOYOTA | Auto and Light Truck | SOLARA | 2001 | 3.0L |
| TOYOTA | Auto and Light Truck | SOLARA | 2002 | 2.4L |
| TOYOTA | Auto and Light Truck | SOLARA | 2002 | 3.0L |
| TOYOTA | Auto and Light Truck | SOLARA | 2003 | 2.4L |
| TOYOTA | Auto and Light Truck | SOLARA | 2003 | 3.0L |
| SND3009 | ND028200-6250 | ARMATURE - STARTER |
| BRG0001 | 35-2204E | BEARING - ROLLER |
| BRG0016 | 35-4000E | BEARING - ROLLER |
| BRG0008 | ND949100-5250 | BEARING - ROLLER |
| SND6605 | | BOOT - STR. B+ TERMINAL |
| SND7525 | ND028099-3430 | BRUSH (GRD) |
| SND7528 | | BRUSH (POS) |
| SND1314 | ND028510-5420 | BRUSH HOLDER - STARTER |
| | | BUSHING |
| SND4611 | ND028062-5790 | DRAIN TUBE |
| | ND028099-6580 | DRIVE ASSY. |
| | ND028099-6590 | DRIVE ASSY. |
| SMT5052 | ND028301-0020 | DRIVE CLUTCH |
| SND5332 | ND028371-6780 | DRIVE PINION (GEAR) |
| | ND028371-6620 | GEAR - INTERMEDIATE |
| SND6604 | | INSULATOR - STR. B+ STUD |
| IHW6204 | | INSULATOR - STR. B+ STUD |
| IHW6206 | | INSULATOR - STR. B+ STUD |
| IHW6212 | | INSULATOR - STR. B+ STUD |
| SND9206 | | O-RING - STARTER |
| SND6455 | ND053660-7151 | PLUNGER |
| | | SOLENOID COIL |
| SND6534 | ND053513-7080 | SOLENOID CONTACT |
| SND6531 | ND053513-0241 | SOLENOID CONTACT |
| | ND028099-7220 | SOLENOID CONTACT KIT - MOTOR |
| SND6547 | | SOLENOID CONTACT SET |
| | ND053404-7061 | SOLENOID GASKET |
| SND2601 | | STEEL BALL |
| SND6521 | | SWITCH TERMINAL |
| HDW1415 | | THRU BOLT - STR. |
